Reflex Level Gauge

Get a Price/Quote

MOQ : 1 Piece

Reflex Level Gauge Specification

Glass Size
As per coustomer request

Display
Direct Reading

Size
15NB, 20NB, 40NB, 50NB Flanged Ends

Material
CS, SS and alloys

Working Presssure
upto 150 bar

Product Type
New

Seal Material
CAF,Teflon, Graphite, Grafoil, Mettalic

Grade
MS,CS, SS

Application
Oil Refineries, Marine Engineering, Food And Beverages Industry, Petro Chemical Plants, Chemical Processing, Pulp And Paper Industry, Nuclear Power Engineering

Color
Green, Blue, Red, Silver, White

Length
CC Range 200 to 3000mm Millimeter (mm)

Reflex Level Gauge Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash Advance (CA), Telegraphic Transfer (T/T)

Supply Ability
2000 Pieces Per Year

Delivery Time
2 Week

Packaging Details
Card Board Box, Wooden Box, Export Box Available

Main Export Market(s)
Asia, Australia, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO, ATEX, IBR, TUV, BV, SGS, IRS

About Reflex Level Gauge

Our Reflex Level Indicators are being used by clients the world over owing to their superior build quality. Used to indicate the pressure and level of liquids within boilers, pressure vessels and tanks, the indicator is today among the most popular in the market. The indicator is highly reliable and delivers safe functioning and accurate readings owing to precision engineering. Assembled along with two auto shut off balls in order to check valve arrangement, the reflex level gauges are in keeping with safety standards.

We are today catering to clients in Dubai, Abu Dhabi, Sharjah, UAE, Kuwait, Oman, Qatar, Egypt, Thailand, Indonesia, Singapore, Malaysia, Myanmar, Vietnam, Brunei, Australlia, Europe, Italy, Belgium.

Reflex Level IndicatorSpecifications:

Minimum Order Quantity	2 Number
CC Distance	250 to 5000 mm
Brand	Beekay - Made In India
Application	Industrial
Model No	BK-RLI-1000-SS
Accuracy	100%
Temperature Range	upto 300 deg C
Measuring Range	upto 3000mm
Usage/Application	Industrial
pressureupto	upto 100 bar
Temperature	1500 Deg C
Pressure	200 bar
Connections	Both Flanged and Screwed End Possible

Robust Construction for Various Industries

Engineered to meet rigorous application demands, the Reflex Level Gauge is constructed using premium materials such as carbon steel, stainless steel, and specialty alloys. Its adaptable design ensures compatibility with diverse industrial settings, from petrochemical facilities to nuclear power plants, offering reliable measurement in challenging conditions.

Customizable and Versatile Options

Customers can tailor their gauges with glass sizes as per request, color preferences (green, blue, red, silver, white), and a selection of sizes ranging from 15NB to 50NB with flanged ends. A comprehensive range of seal materialsincluding CAF, Teflon, graphite, grafoil, and metallicensures optimal sealing and compatibility with process requirements.

FAQs of Reflex Level Gauge:

Q: How does a Reflex Level Gauge work in high-pressure applications?

A: A Reflex Level Gauge uses specially designed glass and robust sealing to visually indicate liquid level, even under pressures up to 100150 bar. Its prism glass technology produces distinct light refraction, showing clear differentiation between liquid and vapor phases for straightforward direct reading.

Q: What industries are best suited for this Reflex Level Gauge?

A: This gauge is ideally suited for industrial sectors like oil refineries, marine engineering, food and beverage, chemical processing, pulp and paper, petrochemical plants, and nuclear power engineering, thanks to its durability and compatibility with aggressive environments.

Q: When should I consider selecting a particular seal material?

A: Seal material selection depends on your process media and operating conditions. For corrosive or high-temperature applications, materials like Teflon, graphite, or grafoil offer superior performance. For more general applications, CAF or metallic seals may suffice.

Q: Where can the Reflex Level Gauge be installed?

A: The gauge is designed for direct installation on storage tanks, process vessels, or pipelines, utilizing flanged ends (15NB50NB), and can be adapted to site-specific requirements. Its robust construction allows operation in both indoor and outdoor industrial setups.

Q: What is the process for ordering a customized gauge?

A: You can request customization based on measuring range (2003000mm), size, color, glass dimensions, and material grade. Provide your specifications during inquiry, and the manufacturer will tailor the gauge accordingly to fit your process needs.

Q: What are the primary benefits of using this Reflex Level Gauge?

A: Key advantages include direct and accurate level indication, adaptability to high-pressure and temperature environments, customizable configurations, reliable sealing, and straightforward installation and maintenance, supported by an 18-month warranty.
